H-24 F650 Digital Bay Controller GEK-106310AB
H.2 FACTORY DEFAULT CONFIGURATION APPENDIX H
H
SENS GND IOC2 BLK
GROUP 2 BLOCKED
SENS GND DIR2 OP NOT
LATCHED VIRT IP 4
SENS GND IOC3 BLK
GROUP 3 BLOCKED
SENS GND DIR3 OP NOT
LATCHED VIRT IP 4
PH TOC1 HIGH A BLK
GROUP 1 BLOCKED
CONT IP_F_CC3 (51P BLOCK)(CC3)
PHASE DIR1 A OP NOT
LATCHED VIRT IP 5
PH TOC1 HIGH B BLK
GROUP 1 BLOCKED
CONT IP_F_CC3 (51P BLOCK)(CC3)
PHASE DIR1 B OP NOT
LATCHED VIRT IP 5
PH TOC1 HIGH C BLK
GROUP 1 BLOCKED
CONT IP_F_CC3 (51P BLOCK)(CC3)
PHASE DIR1 C OP NOT
LATCHED VIRT IP 5
PH TOC2 HIGH A BLK
GROUP 2 BLOCKED
CONT IP_F_CC3 (51P BLOCK)(CC3)
PHASE DIR2 A OP NOT
LATCHED VIRT IP 5
PH TOC2 HIGH B BLK
GROUP 2 BLOCKED
CONT IP_F_CC3 (51P BLOCK)(CC3)
PHASE DIR2 B OP NOT
LATCHED VIRT IP 5
PH TOC2 HIGH C BLK
GROUP 2 BLOCKED
CONT IP_F_CC3 (51P BLOCK)(CC3)
PHASE DIR2 C OP NOT
LATCHED VIRT IP 5
PH TOC3 HIGH A BLK
GROUP 3 BLOCKED
CONT IP_F_CC3 (51P BLOCK)(CC3)
PHASE DIR3 A OP NOT
LATCHED VIRT IP 5
PH TOC3 HIGH B BLK
GROUP 3 BLOCKED
CONT IP_F_CC3 (51P BLOCK)(CC3)
PHASE DIR3 B OP NOT
LATCHED VIRT IP 5
PH TOC3 HIGH C BLK
GROUP 3 BLOCKED
CONT IP_F_CC3 (51P BLOCK)(CC3)
PHASE DIR3 C OP NOT
LATCHED VIRT IP 5
NEUTRAL TOC1 BLOCK
GROUP 1 BLOCKED
NEUTRAL DIR1 OP NOT
NEUTRAL TOC2 BLOCK
GROUP 2 BLOCKED
NEUTRAL DIR2 OP NOT
NEUTRAL TOC3 BLOCK
GROUP 3 BLOCKED
NEUTRAL DIR3 OP NOT
SETPOINT>RELAY CONFIGURATION>PROTECTION ELEMENTS
PROTECTION ELEMENT SOURCE SIGNAL LOGIC SOURCE LOGIC
