H-28 F650 Digital Bay Controller GEK-106310AB
H.2 FACTORY DEFAULT CONFIGURATION APPENDIX H
H
32N1 HIGH BLOCK GROUP 1 BLOCKED
32N2 HIGH BLOCK GROUP 2 BLOCKED
32N3 HIGH BLOCK GROUP 3 BLOCKED
32N1 LOW BLOCK GROUP 1 BLOCKED
32N2 LOW BLOCK GROUP 2 BLOCKED
32N3 LOW BLOCK GROUP 3 BLOCKED
THERMAL1 A RST OPERATION BIT 4
THERMAL1 B RST OPERATION BIT 4
THERMAL1 C RST OPERATION BIT 4
THERMAL2 A RST OPERATION BIT 4
THERMAL2 B RST OPERATION BIT 4
THERMAL2 C RST OPERATION BIT 4
THERMAL3 A RST OPERATION BIT 4
THERMAL3 B RST OPERATION BIT 4
THERMAL3 C RST OPERATION BIT 4
Synchrocheck BLK INP Not Configured
AR LEVEL BLOCK
CONT IP_F_CC8 (79 BLOCK)(CC8)
LATCHED VIRT IP 14
AR PULSE BLOCK Not Configured
AR PULSE UNBLOCK Not Configured
AR INITIATE
VO_083_GENERAL_TRIP
CONT IP_F_CC7 (79 INITIATE)(CC7)
LATCHED VIRT IP 13
AR CONDS INPUT
SYNCHK CLOSE PERM NOT
NOT
LATCHED VIRT IP 15
BKR FAIL INITIATE Not Configured
GROUP 1 ACT ON Not Configured
GROUP 2 ACT ON Not Configured
GROUP 3 ACT ON Not Configured
FAULT REPORT TRIGG VO_083_GENERAL_TRIP
CLEAR FAULT REPORTS Not Configured
DEMAND TRIGGER INP Not Configured
DEMAND RESET INP OPERATION BIT 7
FREEZE ENERGY CNT Not Configured
UNFREEZE ENERGY
CNT
Not Configured
RESET ENERGY CNT OPERATION BIT 6
RESET KI2t COUNTERS OPERATION BIT 5
RESET BKR COUNTERS OPERATION BIT 5
SETPOINT>RELAY CONFIGURATION>OSCILLOGRAPHY
DIGITAL CHANNEL NAME SOURCE SIGNAL LOGIC SOURCE LOGIC
DIG_CHANNEL#1 TRIP VO_083_GENERAL_TRIP
DIG_CHANNEL#2 50/51P TRIP VO_019_PHASE_OVERCURRENT_TRIP
DIG_CHANNEL#3 50/51G TRIP
VO_069_GROUND_OVERCURRENT_T
RIP
DIG_CHANNEL#4 27 TRIP VO_073_27P_TRIP
DIG_CHANNEL#5 59 TRIP VO_074_59P_TRIP
DIG_CHANNEL#6 PICKUP VO_085_GENERAL_PKP
SETPOINT>RELAY CONFIGURATION>PROTECTION ELEMENTS
PROTECTION ELEMENT SOURCE SIGNAL LOGIC SOURCE LOGIC
