GEK-106310AB F650 Digital Bay Controller H-31
APPENDIX H H.2 FACTORY DEFAULT CONFIGURATION
H
SETPOINT>RELAY CONFIGURATION>EVENTS
EVENT NAME SOURCE SIGNAL LOGIC SOURCE LOGIC
EV1 Not Configured
EV2 Not Configured
... ...
EV128 Not Configured
SETPOINT>RELAY CONFIGURATION>SWITCHGEAR
SWITCHGEAR SETTING VALUE/SOURCE SIGNAL LOGIC SOURCE LOGIC
SWITCHGEAR 1
CONTACTS 52b
OPENING TIME 1000
CLOSING TIME 1000
CONTACT A SOURCE N/A
CONTACT B SOURCE CONT IP_F_CC1 (52b)(CC1)
OPEN TEXT 52 OPEN
ALARM NO
CLOSED TEXT 52 CLOSE
ALARM NO
ERROR 00 TEXT 52 ERROR
ALARM N/A
ERROR 11 TEXT 52 UNDEFINED
ALARM N/A
OPENING INIT OPERATION BIT 2
CLOSING INIT OPERATION BIT 1
SWITCHGEAR 2
CONTACTS Not Configured
OPENING TIME Not Configured
CLOSING TIME Not Configured
CONTACT A SOURCE Not Configured
CONTACT B SOURCE Not Configured
OPEN TEXT Not Configured
ALARM Not Configured
CLOSED TEXT Not Configured
ALARM Not Configured
ERROR 00 TEXT Not Configured
ALARM Not Configured
ERROR 11 TEXT Not Configured
ALARM Not Configured
OPENING INIT Not Configured
CLOSING INIT Not Configured
...
... ... ... ...
SETPOINT>RELAY CONFIGURATION>OPERATIONS
OPERATION OPERATION TEXT SETTINGS VALUE/SOURCE
