D
IRECTION 5813707-100, REVISION 2 HAWAII™ SERVICE MANUAL
Chapter 5 - Venue Go™Components and Function (Theory) 5-5
PRELIMINARY
5-3-1 External Power Supply Section
The External Power Supply section provides power via the external AC/DC 24 V adapter.
5-3-2 Venue Go™ User Interface Components
Status and Control panel contain the following functions:
On/Off Touch Button with Green and orange led indicator
Internal Battery Status with Green and Orange Indicator
System Failure Indicator
Optional External Battery Status with Green and Orange Indicator (for future External large
Battery
on
Cart)
Light Sensors
5-3-2-1 LED Indicators Modes
5-3-2-1-1 AC Power Indicator
5-3-2-1-2 Power On/Off Button States
The Power button frame provides additional indication of the current power supply state. When
pressing the On/Off button, the frame is highlighted with the same color as power indicator.
Table 5-2 AC Power Indicator
ON OFF
