GE HEALTHCARE
DIRECTION 5162630, REVISION 3 LOGIQ™ S6 SERVICE MANUAL
8-30 Section 8-3 - Software Loading Procedures (R7.7.x or later with BEP4)
8-3-8-6 TCP/IP Filter Setup (cont’d)
7.) If your system has no TCP port numbers as follows, perform these procedure to add the TCP port
numbers. If the TCP port already have been set, skip these procedures. (This depends on the
network card installed in the PC box.)
* At first check mark Enable TCP/IP Filtering (All adapters).
* Check mark Permit Only in TCP ports box
*Click Add... button.
* Enter 21 (port number) as the TCP Port ,then click OK button to apply it.
* Repeat these procedures to register 21, 23, 80, 104, 512, 3003, 5800, 5801, 5900, and
5901 for TCP ports.
Figure 8-145 TCP/IP Setting
NOTICE
UDP Ports and IP Protocols must be kept default settings.
The TCP port numbers, 21, 23, 80, 104, 512, 3003,
5800, 5801, 5900, and 5901, have been set.
No TCP port number is set. They must
be set.
To Next Page
