GE MOTOR MANAGER 2 User Manual

GE Power Management
MM2 Motor Manager 2 6-21
6 COMMUNICATIONS 6.5 MEMORY MAP
6
STATUS
continued
30033 32 0020 Speed Status Flags --- --- --- F110 N/A
30034 33 0021 Cause of Stop --- --- --- F5 N/A
30035 34 0022 Command Mode --- --- --- F6 N/A
30036 35 0023 Motor Status --- --- --- F7 N/A
30037 36 0024 Motor Mode --- --- --- F8 N/A
30038 37 0025 Active Full Load Current --- --- --- F1 N/A
30039 38 0026 Active Phase CT Primary --- --- --- F1 N/A
30040 39 0027 Cause Of Duty Trip Alarm --- --- --- F9 N/A
30041 40 0028 Cause of Last Stop --- --- --- F5 N/A
30042 41 0029 Trip Type F114 N/A
30043 42 002A Quick Status F115 N/A
30044 43 002B ...Reserved... ... ... ... ... ...
↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓ ↓
30048 47 002F ...Reserved... ... ... ... ... ...
MOTOR
DATA
30049 48 0030 Phase Current Scale Factor --- --- --- F1 N/A
30050 49 0031 Phase A Current --- --- ** F1 N/A
30051 50 0032 Phase B Current --- --- ** F1 N/A
30052 51 0033 Phase C Current --- --- ** F1 N/A
30053 52 0034 Ground Current --- --- 0.1 x A F1 N/A
30054 53 0035 Motor Load --- --- %FLC F1 N/A
30055 54 0036 Thermal Capacity --- --- % F1 N/A
30056 55 0037 Current Unbalance --- --- % F1 N/A
30057 56 0038 Acceleration Time --- --- 0.1 x s F1 N/A
30058 57 0039 Last Starting Current --- --- ** F1 N/A
30059 58 003A O/L Time to Trip --- --- s F1 N/A
30060 59 003B Power - high order --- --- 0.1 x kW F3 N/A
30061 60 003C Power - low order --- --- 0.1 x kW F3 N/A
30062 61 003D Power (scaled) --- --- kW F21 N/A
30063 62 003E Energy Used - high order --- --- 0.1 xkWh F2 N/A
30064 63 003F Energy Used - low order --- --- 0.1 xkWh F2 N/A
30065 64 0040 Voltage --- --- V F1 N/A
30066 65 0041 ...Reserved... ... ... ... ... ...
↓↓↓ ↓ ↓ ↓ ↓↓ ↓
30072 71 0047 ...Reserved... ... ... ... ... ...
Table 6–12: MODBUS MEMORY MAP (Sheet 2 of 21)
GROUP MOD-
ICON
REGISTER
ADDRESS DESCRIPTION REGISTE
R VALUE
RANGE
STEP
VALUE
UNITS
AND
SCALE
FOR-
MAT
FACTORY
DEFAULT
VALUE
(CONVERTED)
DEC HEX
Notes: * – Maximum setpoint value and 65535 represent OFF
** – 1/Phase Current Scale Factor x A
*** – 101 represents unlimited
† – Minimum setpoint value represents OFF
~* – 0.1 x A when Hi resolution mode is disabled; 0.01 x A when enabled
