MM2 Motor Manager 2 10-7
10 CONTROL WIRE APPLICATIONS 10.2 HAND/OFF/AUTO CONFIGURATION
10
10.2.5 3 WIRE HAND / 3 WIRE AUTO
This control scheme is used when it is desirable to operate the starter manually and automatically. In
the Hand position, the starter coil is energized via the START button and de-energized via the STOP
button. In the auto position, the starter is energized automatically when the PLC1 contact is pulsed
closed. When the PLC2 contact is pulsed open, the motor stops.
To program the MM2 for three-wire hand / two-wire auto control, set the MM2 to the default settings.
10.2.6 CONTROL OPERATION
HAND:
• In the hand position, the motor is available to start.
• When the START button is pressed, the motor runs.
• When the STOP button is pressed, the motor stops.
OFF:
• In the off position, the motor will stop.
AUTO:
• In the auto position, the motor is available to start.
• When the PLC contact is pulsed closed, the motor runs.
• When the PLC contact is pulsed open, the motor stops.
• When the STOP button is pressed, the motor stops.
Terminal 11 (Stop input) must be closed to allow a start. The MM2 display will read “Motor Status
Unavailable” when the stop input is open.
If feedback is not received by the Contactor A Status N.O. input within one second of closing Contac-
tor A output relay, an OPEN CONTROL CIRCUIT alarm will occur. This will cause Contactor A output
relay to open.
