GE MOTOR MANAGER 2 User Manual

GE Power Management
MM2 Motor Manager 2 4-27
4 SETPOINTS 4.4 S3 PROCESS
4
ANALOG TRIP LOW
OVERRIDE: 5 s
Range: 1 to 125 seconds or OFF; Step: 1
The analog level must reach a healthy state (greater than trip level)
after a start within the amount of time set by this setpoint. If the value is
0, the analog level must be healthy when a start is initiated or an analog
trip will occur immediately. If set to OFF, the trip will occur if the analog
level is unhealthy, regardless if the motor is running or stopped.
ANALOG TRIP LOW
DELAY: 5 s
Range: 1 to 600 seconds or OFF; Step: 1 second
The analog input scaled value must be below the ANALOG TRIP LOW
LEVEL for the time specified by this setpoint before a trip will occur.
ANALOG TRIP HIGH
LEVEL: OFF
Range: 1 to 20000 or OFF; Step: 1
If the analog input scaled value exceeds the level set by this setpoint,
an Analog Input High Trip will occur. Note that the trip level must be a
value between the MINIMUM SCALE and MAXIMUM SCALE values.
ANALOG TRIP HIGH
OVERRIDE: 5 s
Range: 1 to 125 seconds or OFF; Step: 1
The analog level must reach a healthy state (less than trip level) after a
start within the amount of time set by this setpoint. If the value is 0, the
analog level must be healthy when a start is initiated or an analog trip
will occur immediately. If the value is set to OFF, the trip will occur if the
analog level is unhealthy, regardless if the motor is running or stopped.
ANALOG TRIP HIGH
DELAY: 5 s
Range: 1 to 600 seconds or OFF; Step: 1 second
The analog input scaled value must be above the ANALOG TRIP HIGH
LEVEL for the time specified by this setpoint before a trip will occur.
