GE MOTOR MANAGER 2 User Manual

6-18 MM2 Motor Manager 2
GE Power Management
6.4 APPLICATIONS 6 COMMUNICATIONS
6
30085 84 0054 Pre Trip Phase C Current F1 11B
30086 85 0055 Pre Trip Ground Current F1 11C
30087 86 0056 Cause of Last Trip F1 11D
30062 61 003D Power (scaled) kW F21 11E
30063 62 003E Energy Used - high order 0.1 x kWhr F2 11F
30064 63 003F Energy Used - low order 0.1 x kWhr F2 120
30065 64 0040 Voltage V F1 121
30073 72 0048 Analog Input units F1 122
30089 88 0058 Running Time hr. F1 123
30090 89 0059 Stopped Time hr. F1 124
30097 96 0060 Number of Starts - high order F2 125
30098 97 0061 Number of Starts - low order F2 126
30099 98 0062 Total Trips F1 127
30100 99 0063 Overload Trips F1 128
30101 100 0064 Thermistor Trips F1 129
30102 101 0065 Ground Fault Trips F1 12A
30103 102 0066 Single Phase Trips F1 12B
30104 103 0067 Acceleration Time Trips F1 12C
30105 104 0068 Undercurrent Trips F1 12D
30106 105 0069 Underpower Trips F1 12E
30107 106 006A Stalled Rotor Trips F1 12F
30108 107 006B Control Command Trips F1 130
30109 108 006C Interlock Counter F1 131
Table 6–11: MM2 MEMORY MAP USER DEFINABLE OUTPUTS (Sheet 2 of 2)
MODICON
REGULAR
ADDRESS
DESCRIPTION
REGISTER
VALUE
RANGE
STEP
VALUE
UNITS
AND
SCALE
FORMAT
USER MAP
DEFAULT
ADDRESS
(HEX)
DEC HEX
Shading codes:
Regular Polling
Upon a Trip, Alarm, Stop
Monitor as time permits
