6–10 PQM POWER QUALITY METER – INSTRUCTION MANUAL
UPGRADING FIRMWARE CHAPTER 6: SOFTWARE
Z Do not proceed unless you have saved the current setpoints as
shown in Section 6.4.2: Save/Print PQM Setpoints to a File above.
Z Locate the file to load into the PQM.
The firmware filename has the following format:
Z Select the required file.
Z Click on
OK to proceed or Cancel to abort the firmware upgrade.
65 C 366 C4 . 000
Modification number (000 = none)
For GE Power Management use only
Product firmware revision (e.g. 350 = 3.50). This number
must be larger than the current number of the PQ M. This
number is found in actual values page A4 under SOFTWARE
VERSIONS \ MAIN PROGRAM VERSION.
Required product hardware revision. This letter must
match the first character of the serial number located on
the PQM product label (on the back of the unit)
Product Name (65 = PQM)
