1–8 PQM POWER QUALITY METER – INSTRUCTION MANUAL

STANDARD FEATURES CHAPTER 1: OVERVIEW

FIGURE 1–7: Harmonic Spectrum

Voltage and current waveforms can be captured and displayed on a PC with EnerVista

PQM Setup or third party software. Distorted peaks or notches from SCR switching provide

clues for taking corrective action.

FIGURE 1–8: Captured Waveform

Courtesy of NationalSwitchgear.com
