PQM POWER QUALITY METER – INSTRUCTION MANUAL 8–1
PQM Power Quality Meter
Chapter 8: DNP Communications
GE Consumer & Industrial
Multilin
STATUS COMMUNICATE RELAYS
VALUE
MESSAGE
ACTUAL
SETPOINT
RESET
STORE
SIMULATION
ALARM
SELF TEST
PROGRAM
TX2
TX1
RX2
RX1
AUX2
ALARM
AUX3
AUX1
PQM Power Quality Meter
g
Ia = 100 Ib = 102
Ic = 100 AMPS
DNP Communicati ons
8.1 DNP 3.0 Protocol
8.1.1 Device Profile
Document
The communications port configured as a DNP slave port must support the full set of
features listed in the Level 2 DNP V3.00 Implementation (DNP-L2) described in Chapter 2 of
the subset definitions.
