Chapter 7 – Configuration
206
REASON SWITCHES-TM-EN-3
frames based in many
parameters including its
Control value. Values must be
inserted in hexadecimal
format.
 SNAP: indicates which SNAP will be allowed in this QCE.
When selected, the SNAP Parameters will be displayed.
Possible configuration is as follows:
 PID: indicates which filter should be applied
based on the PID (Protocol Identifier field at the
SNAP field) field on the frame. Possible
configuration is as follows:
o Any: indicates that all incoming frames
will be used at this QCE;
o Specific: only protocol identifiers (PID)
configured will be used at this QCE, that
is, this entry will map frames based in
many parameters including its PID
value. Values must be inserted in
hexadecimal format.
 IPv4: indicates which IPv4 values will be allowed in this
QCE. When selected, the IPv4 Parameters will be
displayed. Possible configuration is as follows:
 Protocol: indicates which filter should be applied
based on the IPv4 protocol number field at the
frame. Possible configuration is as follows:
o Any: indicates that all incoming frames
will be used at this QCE;
o UDP: indicates that only UDP will be
used at this QCE, that is, this entry will
map frames based in many parameters
including if it is a UDP protocol. When
selected, the UDP Parameters will be
displayed. Possible configuration is as
follows:
 Sport: indicates which source
UDP ports will be used at this
QCE. Possible configuration is
as follows:
 Any: indicates that all
incoming frames will be
used at this QCE;
 Specific: indicates that
only specified UDP port
will be used at this QCE.
