5.6.9 GROUND CURRENT
a) MAIN MENU
PATH: SETTINGS  GROUPED ELEMENTS  SETTING GROUP 1(6)  GROUND CURRENT
The T60 relay contains six Ground Time Overcurrent elements, eight Ground Instantaneous Overcurrent elements, and
four Restricted Ground Fault elements. For information on the Ground Time Overcurrent curves, see Inverse TOC Charac-
teristics on page 5–223.
 GROUND CURRENT

 GROUND TOC1

See page 5–243.
MESSAGE
 GROUND TOC2


MESSAGE
 GROUND TOC6

MESSAGE
 GROUND IOC1

See page 5–244.
MESSAGE
 GROUND IOC2


MESSAGE
 GROUND IOC8

MESSAGE
 RESTRICTED GROUND
 FAULT 1
See page 5–245.
MESSAGE
 RESTRICTED GROUND
 FAULT 2
MESSAGE
 RESTRICTED GROUND
 FAULT 3
MESSAGE
 RESTRICTED GROUND
 FAULT 4
