GE Multilin T60 Transformer Protection System 2-9
2 PRODUCT DESCRIPTION 2.2 ORDER CODES
2
2.2ORDER CODES 2.2.1 OVERVIEW
The T60 is available as a 19-inch rack horizontal mount or reduced-size (¾) vertical unit and consists of the following mod-
ules: power supply, CPU, CT/VT, contact input and output, transducer input and output, and inter-relay communications.
Each of these modules can be supplied in a number of configurations specified at the time of ordering. The information
required to completely specify the relay is provided in the following tables (see chapter 3 for full details of relay modules).
Order codes are subject to change without notice. See the ordering page at
http://www.gedigitalenergy.com/multilin/order.htm
for the latest ordering options.
The order code structure is dependent on the mounting option (horizontal or vertical) and the type of CT/VT modules
(enhanced diagnostic CT/VT modules or HardFiber
TM
process bus modules). The order code options are described in the
following sub-sections.
2.2.2 ORDER CODES WITH ENHANCED CT/VT MODULES
The order codes for the horizontal mount units are shown below.
The following features are not available when the T60 is ordered with three CT/VT modules: breaker arcing current,
load encroachment, and breaker failure.
Table 2–4: T60 ORDER CODES (HORIZONTAL UNITS)
T60 - * ** - * * * - F ** - H ** - M ** - P ** - U ** - W/X ** Full Size Horizontal Mount
BASE UNIT T60 | | | | | | | | | | | Base Unit
CPU T | | | | | | | | | | RS485 and Three Multi-mode fiber 100Base-FX (SFP with LC)
U | | | | | | | | | | RS485 and Two Multi-mode fiber 100Base-FX (SFP with LC), One 10/100Base-T (SFP with RJ45)
V | | | | | | | | | | RS485 and Three 10/100Base-T (SFP with RJ45)
SOFTWARE 00 | | | | | | | | | No Software Options
01 | | | | | | | | | Ethernet Global Data (EGD);
03 | | | | | | | | | IEC 61850
04 | | | | | | | | | Ethernet Global Data (EGD) and IEC 61850
06 | | | | | | | | | Phasor Measurement Unit (PMU)
07 | | | | | | | | | IEC 61850 communications and Phasor Measurement Unit (PMU)
10 | | | | | | | | | Synchrocheck
11 | | | | | | | | | Synchrocheck and IEC 61850
20 | | | | | | | | | Six windings
21 | | | | | | | | | Six windings and Ethernet Global Data (EGD) protocol
22 | | | | | | | | | Six windings and IEC 61850 protocol
23 | | | | | | | | | Six windings, Ethernet Global Data (EGD) protocol, and IEC 61850 protocol
33 | | | | | | | | | Phasor Measurement Unit (PMU) and synchrocheck
34 | | | | | | | | | Phasor Measurement Unit (PMU), IEC 61850 protocol, and synchrocheck
A0 | | | | | | | | | CyberSentry Lvl 1
A1 | | | | | | | | | CyberSentry Lvl 1 and Ethernet Global Data (EGD)
A3 | | | | | | | | | CyberSentry Lvl 1 and IEC 61850
A4 | | | | | | | | | CyberSentry Lvl 1 and IEC 61850 and Ethernet Global Data (EGD)
A6 | | | | | | | | | CyberSentry Lvl 1 and Phasor Measurement Unit (PMU)
A7 | | | | | | | | | CyberSentry Lvl 1 and IEC 61850 and Phasor Measurement Unit (PMU)
AA | | | | | | | | | CyberSentry Lvl 1 and synchrocheck
AB | | | | | | | | | CyberSentry Lvl 1 and IEC 61850 and synchrocheck
AK | | | | | | | | | CyberSentry Lvl 1 and six windings
AL | | | | | | | | | CyberSentry Lvl 1 and Ethernet Global Data (EGD) and six windings
AM | | | | | | | | | CyberSentry Lvl 1 and IEC 61850 and six windings
AN | | | | | | | | | CyberSentry Lvl 1 and IEC 61850 and Ethernet Global Data (EGD) and six windings
AX | | | | | | | | | CyberSentry Lvl 1 and Phasor Measurement Unit (PMU) and synchrocheck
AY | | | | | | | | | CyberSentry Lvl 1 and IEC 61850 and Phasor Measurement Unit (PMU) and synchrocheck
B0 | | | | | | | | | IEEE 1588
B1 | | | | | | | | | IEEE 1588 and Ethernet Global Data (EGD)
B3 | | | | | | | | | IEEE 1588 and IEC 61850
B4 | | | | | | | | | IEEE 1588 and IEC 61850 and Ethernet Global Data (EGD)
B6 | | | | | | | | | IEEE 1588 and Phasor Measurement Unit (PMU)
B7 | | | | | | | | | IEEE 1588 and IEC 61850 and Phasor Measurement Unit (PMU)
BA | | | | | | | | | IEEE 1588 and synchrocheck
BB | | | | | | | | | IEEE 1588 and IEC 61850 and synchrocheck
BK | | | | | | | | | IEEE 1588 and six windings
BL | | | | | | | | | IEEE 1588 and Ethernet Global Data (EGD) and six windings
BM | | | | | | | | | IEEE 1588 and IEC 61850 and six windings
BN | | | | | | | | | IEEE 1588 and IEC 61850 and Ethernet Global Data (EGD) and six windings
BX | | | | | | | | | IEEE 1588 and Phasor Measurement Unit (PMU) and synchrocheck
BY | | | | | | | | | IEEE 1588 and IEC 61850 and Phasor Measurement Unit (PMU) and synchrocheck
C0 | | | | | | | | | Parallel Redundancy Protocol (PRP)
C1 | | | | | | | | | PRP and Ethernet Global Data (EGD)
C3 | | | | | | | | | PRP and IEC 61850
C4 | | | | | | | | | PRP, Ethernet Global Data (EGD), and IEC 61850
C6 | | | | | | | | | PRP and PMU
C7 | | | | | | | | | PRP, IEC 61850, and PMU
CA | | | | | | | | | PRP and Synchrocheck
CB | | | | | | | | | PRP, IEC 61850, and Synchrocheck
CK | | | | | | | | | PRP and six windings
CL | | | | | | | | | PRP, six windings, and Ethernet Global Data
CM | | | | | | | | | PRP, six windings, and IEC 61850
CN | | | | | | | | | PRP, six windings, Ethernet Global Data, and IEC 61850
CX | | | | | | | | | PRP, PMU, and Synchrocheck
CY | | | | | | | | | PRP, PMU, IEC 61850, and Synchrocheck
D0 | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1
D1 | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and Ethernet Global Data (EGD)
D3 | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850
D4 | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850 and Ethernet Global Data (EGD)
D6 | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and Phasor Measurement Unit (PMU)
D7 | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850 and Phasor Measurement Unit (PMU)
DA | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and synchrocheck
DB | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 IEC 61850 and synchrocheck
DK | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and six windings
DL | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and Ethernet Global Data (EGD) and six windings
DM | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850 and six windings
DN | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850 and Ethernet Global Data (EGD) and six windings
DX | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and Phasor Measurement Unit (PMU) and synchrocheck
DY | | | | | | | | | IEEE 1588 and CyberSentry Lvl 1 and IEC 61850 and Phasor Measurement Unit (PMU) and synchrocheck
E0 | | | | | | | | | IEEE 1588 and PRP
E1 | | | | | | | | | IEEE 1588, PRP, and Ethernet Global Dada
E3 | | | | | | | | | IEEE 1588, PRP, and IEC 61850
E4 | | | | | | | | | IEEE 1588, PRP, Ethernet Global Data, and IEC 61850
E6 | | | | | | | | | IEEE 1588, PRP, and PMU
E7 | | | | | | | | | IEEE 1588, PRP, IEC 61850, and PMU
EA | | | | | | | | | IEEE 1588, PRP, and Synchrocheck
