GE Multilin T60 Transformer Protection System 2-33
2 PRODUCT DESCRIPTION 2.3 SPECIFICATIONS
2
2.3.13 APPROVALS
APPROVALS
2.3.14 MAINTENANCE
MOUNTING
Attach mounting brackets using 20 inch-pounds (±2 inch-pounds)
of torque.
CLEANING
Normally, cleaning is not required; but for situations where dust
has accumulated on the faceplate display, a dry cloth can be used.
To avoid deterioration of electrolytic
capacitors, power up units that are stored
in a de-energized state once per year, for
one hour continuously.
COMPLIANCE APPLICABLE
COUNCIL DIRECTIVE
ACCORDING TO
CE Low voltage directive EN 60255-5
EMC directive EN 60255-26 / EN 50263
EN 61000-6-5
C-UL-US --- UL 508
UL 1053
C22.2 No. 14
