GE Multilin T60 Transformer Protection System A-21
APPENDIX A A.1 PARAMETER LISTS
A
10753 SRC 6 Ia Harm[17] Amps Source 6 phase A current nineteenth harmonic
10754 SRC 6 Ia Harm[18] Amps Source 6 phase A current twentieth harmonic
10755 SRC 6 Ia Harm[19] Amps Source 6 phase A current twenty-first harmonic
10756 SRC 6 Ia Harm[20] Amps Source 6 phase A current twenty-second harmonic
10757 SRC 6 Ia Harm[21] Amps Source 6 phase A current twenty-third harmonic
10758 SRC 6 Ia Harm[22] Amps Source 6 phase A current twenty-fourth harmonic
10759 SRC 6 Ia Harm[23] Amps Source 6 phase A current twenty-fifth harmonic
10768 SRC 6 Ib THD --- Source 6 phase B current total harmonic distortion
10769 SRC 6 Ib Harm[0] Amps Source 6 phase B current second harmonic
10770 SRC 6 Ib Harm[1] Amps Source 6 phase B current third harmonic
10771 SRC 6 Ib Harm[2] Amps Source 6 phase B current fourth harmonic
10772 SRC 6 Ib Harm[3] Amps Source 6 phase B current fifth harmonic
10773 SRC 6 Ib Harm[4] Amps Source 6 phase B current sixth harmonic
10774 SRC 6 Ib Harm[5] Amps Source 6 phase B current seventh harmonic
10775 SRC 6 Ib Harm[6] Amps Source 6 phase B current eighth harmonic
10776 SRC 6 Ib Harm[7] Amps Source 6 phase B current ninth harmonic
10777 SRC 6 Ib Harm[8] Amps Source 6 phase B current tenth harmonic
10778 SRC 6 Ib Harm[9] Amps Source 6 phase B current eleventh harmonic
10779 SRC 6 Ib Harm[10] Amps Source 6 phase B current twelfth harmonic
10780 SRC 6 Ib Harm[11] Amps Source 6 phase B current thirteenth harmonic
10781 SRC 6 Ib Harm[12] Amps Source 6 phase B current fourteenth harmonic
10782 SRC 6 Ib Harm[13] Amps Source 6 phase B current fifteenth harmonic
10783 SRC 6 Ib Harm[14] Amps Source 6 phase B current sixteenth harmonic
10784 SRC 6 Ib Harm[15] Amps Source 6 phase B current seventeenth harmonic
10785 SRC 6 Ib Harm[16] Amps Source 6 phase B current eighteenth harmonic
10786 SRC 6 Ib Harm[17] Amps Source 6 phase B current nineteenth harmonic
10787 SRC 6 Ib Harm[18] Amps Source 6 phase B current twentieth harmonic
10788 SRC 6 Ib Harm[19] Amps Source 6 phase B current twenty-first harmonic
10789 SRC 6 Ib Harm[20] Amps Source 6 phase B current twenty-second harmonic
10790 SRC 6 Ib Harm[21] Amps Source 6 phase B current twenty-third harmonic
10791 SRC 6 Ib Harm[22] Amps Source 6 phase B current twenty-fourth harmonic
10792 SRC 6 Ib Harm[23] Amps Source 6 phase B current twenty-fifth harmonic
10801 SRC 6 Ic THD --- Source 6 phase C current total harmonic distortion
10802 SRC 6 Ic Harm[0] Amps Source 6 phase C current second harmonic
10803 SRC 6 Ic Harm[1] Amps Source 6 phase C current third harmonic
10804 SRC 6 Ic Harm[2] Amps Source 6 phase C current fourth harmonic
10805 SRC 6 Ic Harm[3] Amps Source 6 phase C current fifth harmonic
10806 SRC 6 Ic Harm[4] Amps Source 6 phase C current sixth harmonic
10807 SRC 6 Ic Harm[5] Amps Source 6 phase C current seventh harmonic
10808 SRC 6 Ic Harm[6] Amps Source 6 phase C current eighth harmonic
10809 SRC 6 Ic Harm[7] Amps Source 6 phase C current ninth harmonic
10810 SRC 6 Ic Harm[8] Amps Source 6 phase C current tenth harmonic
10811 SRC 6 Ic Harm[9] Amps Source 6 phase C current eleventh harmonic
10812 SRC 6 Ic Harm[10] Amps Source 6 phase C current twelfth harmonic
10813 SRC 6 Ic Harm[11] Amps Source 6 phase C current thirteenth harmonic
10814 SRC 6 Ic Harm[12] Amps Source 6 phase C current fourteenth harmonic
10815 SRC 6 Ic Harm[13] Amps Source 6 phase C current fifteenth harmonic
Table A–1: FLEXANALOG DATA ITEMS (Sheet 21 of 25)
ADDRESS FLEXANALOG NAME UNITS DESCRIPTION
