B.4 MEMORY MAPPING APPENDIX B
B
5E9C ...Repeated for CT Fail 5
5EA8 ...Repeated for CT Fail 6
Setting Groups (Read/Write Setting)
5F70 Setting Group for Modbus Comms (0 means group 1) 0 to 5 --- 1 F001 0
5F71 Setting Groups Block 0 to 4294967295 --- 1 F300 0
5F73 FlexLogic to Activate Groups 2 through 6 (5 items) 0 to 4294967295 --- 1 F300 0
5F7D Setting Group Function 0 to 1 --- 1 F102 0 (Disabled)
5F7E Setting Group Events 0 to 1 --- 1 F102 0 (Disabled)
Setting Groups (Read Only)
5F7F Current Setting Group 0 to 5 --- 1 F001 0
Setting Group Names (Read/Write Setting)
5F8C Setting Group 1 Name --- --- --- F203 (none)
5F94 Setting Group 2 Name --- --- --- F203 (none)
5F9C Setting Group 3 Name --- --- --- F203 (none)
5FA4 Setting Group 4 Name --- --- --- F203 (none)
5FAC Setting Group 5 Name --- --- --- F203 (none)
5FB4 Setting Group 6 Name --- --- --- F203 (none)
Transformer Hottest Spot (Read/Write Grouped Setting)
6140 Transformer Hottest Spot Function 0 to 1 --- 1 F102 0 (Disabled)
6141 Transformer Hottest Spot Pickup 50 to 300 °C 1 F001 140
6142 Transformer Hottest Spot Delay 0 to 30000 min 1 F001 1
6143 Transformer Hottest Spot Block 0 to 4294967295 --- 1 F300 0
6145 Transformer Hottest Spot Target 0 to 2 --- 1 F109 0 (Self-reset)
6146 Transformer Hottest Spot Events 0 to 1 --- 1 F102 0 (Disabled)
Transformer Aging Factor (Read/Write Grouped Setting)
6150 Transformer Aging Factor Function 0 to 1 --- 1 F102 0 (Disabled)
6151 Transformer Aging Factor Pickup 1 to 10 PU 0.1 F001 20
6152 Transformer Aging Factor Delay 0 to 30000 min 1 F001 10
6153 Transformer Aging Factor BLock 0 to 4294967295 --- 1 F300 0
6155 Transformer Aging Factor Target 0 to 2 --- 1 F109 0 (Self-reset)
6156 Transformer Aging Factor Events 0 to 1 --- 1 F102 0 (Disabled)
Transformer Loss of Life (Read/Write Grouped Setting)
6160 Transformer Loss of Life Function 0 to 1 --- 1 F102 0 (Disabled)
6161 XFMR LOL Initial Value 0 to 500000 hrs 1 F003 0
6163 Transformer Loss of Life Pickup 0 to 500000 hrs 1 F003 180000
6165 Transformer Loss Of Life Block 0 to 4294967295 --- 1 F300 0
6167 Transformer Loss of Life Target 0 to 2 --- 1 F109 0 (Self-reset)
6168 Transformer Loss of Life Events 0 to 1 --- 1 F102 0 (Disabled)
Transformer Thermal Inputs (Read/Write Setting)
6170 Transformer Thermal Model Source Input 0 to 5 --- 1 F167 0 (SRC 1)
6171 Ambient Temperature Input Sensor 0 to 32 --- 1 F450 0
6172 Top Oil Temperature Input Sensor 0 to 32 --- 1 F460 0
6173 January Average Ambient Temperature -60 to 60 --- 1 F002 -20
6174 February Average Ambient Temperature -60 to 60 --- 1 F002 -30
6175 March Average Ambient Temperature -60 to 60 --- 1 F002 -10
6176 April Average Ambient Temperature -60 to 60 --- 1 F002 10
6177 May Average Ambient Temperature -60 to 60 --- 1 F002 20
6178 June Average Ambient Temperature -60 to 60 --- 1 F002 30
6179 July Average Ambient Temperature -60 to 60 --- 1 F002 30
617A August Average Ambient Temperature -60 to 60 --- 1 F002 30
617B September Average Ambient Temperature -60 to 60 --- 1 F002 20
617C October Average Ambient Temperature -60 to 60 --- 1 F002 10
617D November Average Ambient Temperature -60 to 60 --- 1 F002 10
617E December Average Ambient Temperature -60 to 60 --- 1 F002 -10
Table B–10: MODBUS MEMORY MAP (Sheet 34 of 74)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
