B-52 T60 Transformer Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
8618 Breaker Failure 1 Neutral Amp Hiset Pickup 0.001 to 30 pu 0.001 F001 1050
8619 Breaker Failure 1 Phase Amp Loset Pickup 0.001 to 30 pu 0.001 F001 1050
861A Breaker Failure 1 Neutral Amp Loset Pickup 0.001 to 30 pu 0.001 F001 1050
861B Breaker Failure 1 Loset Time 0 to 65.535 s 0.001 F001 0
861C Breaker Failure 1 Trip Dropout Delay 0 to 65.535 s 0.001 F001 0
861D Breaker Failure 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
861E Breaker Failure 1 Events 0 to 1 --- 1 F102 0 (Disabled)
861F Breaker Failure 1 Phase A Initiate 0 to 4294967295 --- 1 F300 0
8621 Breaker Failure 1 Phase B Initiate 0 to 4294967295 --- 1 F300 0
Remote RTD inputs (Read Only Actual Values) (12 Modules)
87C0 Remote RTD 1 Value 0 to 200 °C 1 F002 0
87C1 Remote RTD 2 Value 0 to 200 °C 1 F002 0
87C2 Remote RTD 3 Value 0 to 200 °C 1 F002 0
87C3 Remote RTD 4 Value 0 to 200 °C 1 F002 0
87C4 Remote RTD 5 Value 0 to 200 °C 1 F002 0
87C5 Remote RTD 6 Value 0 to 200 °C 1 F002 0
87C6 Remote RTD 7 Value 0 to 200 °C 1 F002 0
87C7 Remote RTD 8 Value 0 to 200 °C 1 F002 0
87C8 Remote RTD 9 Value 0 to 200 °C 1 F002 0
87C9 Remote RTD 10 Value 0 to 200 °C 1 F002 0
87CA Remote RTD 11 Value 0 to 200 °C 1 F002 0
87CB Remote RTD 12 Value 0 to 200 °C 1 F002 0
FlexState Settings (Read/Write Setting)
8800 FlexState Parameters (256 items) 0 to 4294967295 --- --- F300 0
Digital Elements (Read/Write Setting) (48 Modules)
8A00 Digital Element 1 Function 0 to 1 --- 1 F102 0 (Disabled)
8A01 Digital Element 1 Name --- --- --- F203 “Dig Element 1“
8A09 Digital Element 1 Input 0 to 4294967295 --- 1 F300 0
8A0B Digital Element 1 Pickup Delay 0 to 999999.999 s 0.001 F003 0
8A0D Digital Element 1 Reset Delay 0 to 999999.999 s 0.001 F003 0
8A0F Digital Element 1 Block 0 to 4294967295 --- 1 F300 0
8A11 Digital Element 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
8A12 Digital Element 1 Events 0 to 1 --- 1 F102 0 (Disabled)
8A13 Digital Element 1 Pickup LED 0 to 1 --- 1 F102 1 (Enabled)
8A14 Reserved (2 items) --- --- --- F001 0
8A16 ...Repeated for Digital Element 2
8A2C ...Repeated for Digital Element 3
8A42 ...Repeated for Digital Element 4
8A58 ...Repeated for Digital Element 5
8A6E ...Repeated for Digital Element 6
8A84 ...Repeated for Digital Element 7
8A9A ...Repeated for Digital Element 8
8AB0 ...Repeated for Digital Element 9
8AC6 ...Repeated for Digital Element 10
8ADC ...Repeated for Digital Element 11
8AF2 ...Repeated for Digital Element 12
8B08 ...Repeated for Digital Element 13
8B1E ...Repeated for Digital Element 14
8B34 ...Repeated for Digital Element 15
8B4A ...Repeated for Digital Element 16
8B60 ...Repeated for Digital Element 17
8B76 ...Repeated for Digital Element 18
8B8C ...Repeated for Digital Element 19
8BA2 ...Repeated for Digital Element 20
Table B–10: MODBUS MEMORY MAP (Sheet 44 of 74)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
