B-58 T60 Transformer Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
A28F Selector 1 Bit Acknowledge 0 to 4294967295 --- 1 F300 0
A291 Selector 1 Power Up Mode 0 to 2 --- 1 F084 0 (Restore)
A292 Selector 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
A293 Selector 1 Events 0 to 1 --- 1 F102 0 (Disabled)
A294 Reserved (10 items) --- --- 1 F001 0
A29E ...Repeated for Selector 2
Digital Counter (Read/Write Setting) (8 Modules)
A300 Digital Counter 1 Function 0 to 1 --- 1 F102 0 (Disabled)
A301 Digital Counter 1 Name --- --- --- F205 “Counter 1"
A307 Digital Counter 1 Units --- --- --- F206 (none)
A30A Digital Counter 1 Block 0 to 4294967295 --- 1 F300 0
A30C Digital Counter 1 Up 0 to 4294967295 --- 1 F300 0
A30E Digital Counter 1 Down 0 to 4294967295 --- 1 F300 0
A311 Digital Counter 1 Preset –2147483647 to
2147483647
--- 1 F004 0
A313 Digital Counter 1 Compare –2147483647 to
2147483647
--- 1 F004 0
A315 Digital Counter 1 Reset 0 to 4294967295 --- 1 F300 0
A317 Digital Counter 1 Freeze/Reset 0 to 4294967295 --- 1 F300 0
A319 Digital Counter 1 Freeze/Count 0 to 4294967295 --- 1 F300 0
A31B Digital Counter 1 Set To Preset 0 to 4294967295 --- 1 F300 0
A31D Reserved (11 items) --- --- --- F001 0
A328 ...Repeated for Digital Counter 2
A350 ...Repeated for Digital Counter 3
A378 ...Repeated for Digital Counter 4
A3A0 ...Repeated for Digital Counter 5
A3C8 ...Repeated for Digital Counter 6
A3F0 ...Repeated for Digital Counter 7
A418 ...Repeated for Digital Counter 8
Volts Per Hertz (Read/Write Grouped Setting) (2 Modules)
A580 Volts Per Hertz 1 Function 0 to 1 --- 1 F102 0 (Disabled)
A581 Volts Per Hertz 1 Source 0 to 5 --- 1 F167 0 (SRC 1)
A582 Volts Per Hertz 1 Pickup 0.8 to 4 pu 0.01 F001 80
A583 Volts Per Hertz 1 Curves 0 to 7 --- 1 F240 0 (Definite Time)
A584 Volts Per Hertz 1 TD Multiplier 0.05 to 600 --- 0.01 F001 100
A585 Volts Per Hertz 1 Block 0 to 4294967295 --- 1 F300 0
A587 Volts Per Hertz 1 Events 0 to 1 --- 1 F102 0 (Disabled)
A588 Volts Per Hertz 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
A589 Volts Per Hertz 1 T Reset 0 to 1000 s 0.1 F001 10
A58A Volts Per Hertz 1 Voltage Mode 0 to 1 --- 1 F186 0 (Phase-to-
Ground)
A58B ...Repeated for Volts Per Hertz 2
Volts Per Hertz Actuals (Read Only) (2 Modules)
A5A0 Volts Per Hertz 1 0 to 65.535 pu 0.001 F001 0
A5A1 Volts Per Hertz 2 0 to 65.535 pu 0.001 F001 0
Flexcurves C and D (Read/Write Setting)
A600 FlexCurve C (120 items) 0 to 65535 ms 1 F011 0
A680 FlexCurve D (120 items) 0 to 65535 ms 1 F011 0
Non Volatile Latches (Read/Write Setting) (16 Modules)
A700 Non-Volatile Latch 1 Function 0 to 1 --- 1 F102 0 (Disabled)
A701 Non-Volatile Latch 1 Type 0 to 1 --- 1 F519 0 (Reset
Dominant)
A702 Non-Volatile Latch 1 Set 0 to 4294967295 --- 1 F300 0
A704 Non-Volatile Latch 1 Reset 0 to 4294967295 --- 1 F300 0
A706 Non-Volatile Latch 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
Table B–10: MODBUS MEMORY MAP (Sheet 50 of 74)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
