GE T60

GE Multilin T60 Transformer Protection System B-85
APPENDIX B B.4 MEMORY MAPPING
B
33 Neutral Instantaneous Overcurrent 2
34 Neutral Instantaneous Overcurrent 3
35 Neutral Instantaneous Overcurrent 4
36 Neutral Instantaneous Overcurrent 5
37 Neutral Instantaneous Overcurrent 6
38 Neutral Instantaneous Overcurrent 7
39 Neutral Instantaneous Overcurrent 8
40 Neutral Instantaneous Overcurrent 9
41 Neutral Instantaneous Overcurrent 10
42 Neutral Instantaneous Overcurrent 11
43 Neutral Instantaneous Overcurrent 12
48 Neutral Time Overcurrent 1
49 Neutral Time Overcurrent 2
50 Neutral Time Overcurrent 3
51 Neutral Time Overcurrent 4
52 Neutral Time Overcurrent 5
53 Neutral Time Overcurrent 6
56 Neutral Directional Overcurrent 1
57 Neutral Directional Overcurrent 2
60 Negative Sequence Directional Overcurrent 1
61 Negative Sequence Directional Overcurrent 2
64 Ground Instantaneous Overcurrent 1
65 Ground Instantaneous Overcurrent 2
66 Ground Instantaneous Overcurrent 3
67 Ground Instantaneous Overcurrent 4
68 Ground Instantaneous Overcurrent 5
69 Ground Instantaneous Overcurrent 6
70 Ground Instantaneous Overcurrent 7
71 Ground Instantaneous Overcurrent 8
72 Ground Instantaneous Overcurrent 9
73 Ground Instantaneous Overcurrent 10
74 Ground Instantaneous Overcurrent 11
75 Ground Instantaneous Overcurrent 12
80 Ground Time Overcurrent 1
81 Ground Time Overcurrent 2
82 Ground Time Overcurrent 3
83 Ground Time Overcurrent 4
84 Ground Time Overcurrent 5
85 Ground Time Overcurrent 6
86 Restricted Ground Fault 1
87 Restricted Ground Fault 2
88 Restricted Ground Fault 3
89 Restricted Ground Fault 4
90 Restricted Ground Fault 5
91 Restricted Ground Fault 6
96 Negative Sequence Instantaneous Overcurrent 1
97 Negative Sequence Instantaneous Overcurrent 2
101 Opposite Phase Rotation
112 Negative Sequence Time Overcurrent 1
113 Negative Sequence Time Overcurrent 2
120 Negative Sequence Overvoltage 1
140 Auxiliary Undervoltage 1
144 Phase Undervoltage 1
Bitmask Element
145 Phase Undervoltage 2
146 Phase Undervoltage 3
148 Auxiliary Overvoltage 1
151 Phase Overvoltage 1
152 Phase Overvoltage 2
153 Phase Overvoltage 3
154 Compensated Overvoltage 1
156 Neutral Overvoltage 1
160 Phase Distance Zone 1
161 Phase Distance Zone 2
162 Phase Distance Zone 3
163 Phase Distance Zone 4
164 Phase Distance Zone 5
172 Ground Distance Zone 1
173 Ground Distance Zone 2
174 Ground Distance Zone 3
175 Ground Distance Zone 4
176 Ground Distance Zone 5
180 Load Encroachment
190 Power Swing Detect
202 Transformer Hottest Spot
203 Transformer Aging Factor
204 Transformer Loss of Life
208 Transformer Instantaneous
209 Transformer Percent Differential
210 Volt per Hertz 1
211 Volt per Hertz 2
224 SRC1 VT Fuse Failure
225 SRC2 VT Fuse Failure
226 SRC3 VT Fuse Failure
227 SRC4 VT Fuse Failure
232 SRC1 50DD (Disturbance Detection)
233 SRC2 50DD (Disturbance Detection)
234 SRC3 50DD (Disturbance Detection)
235 SRC4 50DD (Disturbance Detection)
246 CT Failure
280 Breaker Failure 1
281 Breaker Failure 2
282 Breaker Failure 3
283 Breaker Failure 4
288 Breaker Arcing Current 1
289 Breaker Arcing Current 2
290 Breaker Arcing Current 3
291 Breaker Arcing Current 4
292 Breaker Arcing Current 5
293 Breaker Arcing Current 6
311 Phasor measurement unit one-shot
312 Synchrocheck 1
313 Synchrocheck 2
336 Setting Group
337 Reset
388 Selector 1
389 Selector 2
Bitmask Element
