B-90 T60 Transformer Protection System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
F156
ENUMERATION: REMOTE INPUT BIT PAIRS
F157
ENUMERATION: BREAKER MODE
0 = 3-Pole, 1 = 1-Pole
F160
ENUMERATION: TRANSFORMER PHASE COMPENSATION
0 = Internal (software), 1 = External (with CTs)
F161
ENUMERATION: TRANSFORMER RATED WINDING
TEMPERATURE RISE
0 = 55°C (oil), 1 = 65°C (oil), 2 = 80°C (dry), 3 = 115°C (dry),
4 = 150°C (dry)
F162
ENUMERATION: TRANSFORMER TYPE OF COOLING
0 = OA, 1 = FA, 2 = Non-directed FOA/FOW,
3 = Directed FOA/FOW, 4 = Sealed Self Cooled,
5 = Vented Self Cooled, 6 = Forced Cooled
F163
ENUMERATION: TRANSFORMER WINDING CONNECTION
0 = Wye, 1 = Delta, 2 = Zig-zag
F164
ENUMERATION: TRANSFORMER WINDING GROUNDING
0 = Not within zone, 1 = Within zone
F166
ENUMERATION: AUXILIARY VT CONNECTION TYPE
0 = Vn, 1 = Vag, 2 = Vbg, 3 = Vcg, 4 = Vab, 5 = Vbc, 6 = Vca
F167
ENUMERATION: SIGNAL SOURCE
0 = SRC 1, 1 = SRC 2, 2 = SRC 3, 3 = SRC 4,
4 = SRC 5, 5 = SRC 6
F168
ENUMERATION: INRUSH INHIBIT FUNCTION
0 = Disabled, 1 = Adapt. 2nd, 2 = Trad. 2nd
F169
ENUMERATION: OVEREXCITATION INHIBIT FUNCTION
0 = Disabled, 1 = 5th
F172
ENUMERATION: SLOT LETTERS
Bitmask Value Bitmask Value
0 NONE 35 UserSt-3
1 DNA-1 36 UserSt-4
2 DNA-2 37 UserSt-5
3 DNA-3 38 UserSt-6
4 DNA-4 39 UserSt-7
5 DNA-5 40 UserSt-8
6 DNA-6 41 UserSt-9
7 DNA-7 42 UserSt-10
8 DNA-8 43 UserSt-11
9 DNA-9 44 UserSt-12
10 DNA-10 45 UserSt-13
11 DNA-11 46 UserSt-14
12 DNA-12 47 UserSt-15
13 DNA-13 48 UserSt-16
14 DNA-14 49 UserSt-17
15 DNA-15 50 UserSt-18
16 DNA-16 51 UserSt-19
17 DNA-17 52 UserSt-20
18 DNA-18 53 UserSt-21
19 DNA-19 54 UserSt-22
20 DNA-20 55 UserSt-23
21 DNA-21 56 UserSt-24
22 DNA-22 57 UserSt-25
23 DNA-23 58 UserSt-26
24 DNA-24 59 UserSt-27
25 DNA-25 60 UserSt-28
26 DNA-26 61 UserSt-29
27 DNA-27 62 UserSt-30
28 DNA-28 63 UserSt-31
29 DNA-29 64 UserSt-32
30 DNA-30 65 Dataset Item 1
31 DNA-31 66 Dataset Item 2
32 DNA-32 67 Dataset Item 3
33 UserSt-1 
34 UserSt-2 96 Dataset Item 32
Bitmas
k
Slot Bitmas
k
Slot Bitmas
k
Slot Bitmas
k
Slot
0F 4K 8P 12U
1G 5 L 9R 13V
2H 6M 10S 14W
3J 7N 11T 15X
