GE WPGT9350 User Manual

– 37 –
Bearing Housing Assembly
To remove the bearing housing Assembly:
1. Remove the
Motor Assembly and Clutch
Shifter Assembly.
2. Remove the screw that holds the ground wire
to the bearing housing. Remove all the
10-mm hex-head screws on the bearing
housing assembly
Note: When reassembling, be sure to put the
motor and Hall sensor wires back in the wiring
guard away from the motor.
3. Remove the clutch coupler assembly.
4. Disconnect the wiring connector from the
clutch motor.
5. Remove the two 10-mm hex-head screws
that hold the clutch motor in place. Remove
the clutch motor.
To remove the clutch shifter assembly:
1. Remove the rotor. (See
Motor Assembly.)
2. Remove the three Phillips head screws from
the clutch coupler plate.
Disconnect
Ground
4. Remove the bearing housing assembly.
