– 53 –
VIEW
NUMBER
CATALOG NUMBER DESCRIPTION QUANTITY
150 WH47X10004 DETERGENT BOX ASM 1
151 WH47X10005 INSERT, DETERGENT BOX 1
160 WH01X10207 HINGE 2
163 WH02X10148 SCREW 6
170 WH39X10003 MECH HSNG ASM - BEARING 1
180 WH13X10017 VALVE ASM - INLET 1
182 WH41X10084 PIPE 1
184 WH41X10085 HOSE, INLET 1
186 WH41X10086 HOSE, INLET 1
200 WH12X10247 SENSOR SWITCH ASM 1
201 WH41X10087 TUBE, PRESSURE S/W 1
202 WH01X10208 RING, SNAP 1
205 WH39X10004 STATOR ASM 1
210 WH02X10149 BOLT 6
215 WH39X10005 ROTOR ASM 1
230 WH20X10024 MOTOR ASM W/CLUTCH 1
240 WH19X10029 HARNESS, PWB 1
241 WH12X10248 FILTER ASM -CIRC 1
275 WH41X10088 HOSE, INLET 1
276 WH41X10089 HOSE, INLET 1
290 WH41X10090 GUIDE, WATER 1
300 WH01X10209 NUT 1
305 WH02X10150 WASHER 1
340 WH01X10210 COUPLING ASM 1
305 WH02X10150 WASHER 1
345 WH01X10211 COUPLING 1
350 WH12X10249 THERMISTOR ASM 1
360 WH44X10119 COVER, PROTECT 1
380 WH47X10007 BOX, BLEACH 1
390 WH01X10212 CLAMP 4
360 WH44X10119 COVER, PROTECT 1
400 WH12X10250 RESISTOR 1
410 WH01X10213 BLEACH CAP 1
415 WH45X10057 TUB - OUTER 1
421 WE08X10061 CABLE ASSEMBLY 1
422 WH19X10031 CONNECTOR ASM 1
423 WH19X10030 CONNECTOR ASM 1
9996 WH02X10158 SCREW PACK 1
9997 WH02X10159 SCREW PACK 1
422 WE08X10058 CONNECTOR ASM 1
9998 WH02X10160 SCREW PACK 1
