58
EN
3.2.2 Charge the Lithium-ion Battery with the Charger
Connect the charger to the power source.
Only connect to single-phase alternating
current and only to the line voltage indicated
on the power rating plate.
1. Attach the lithium-ion battery to
the charger as shown. The charging
process starts automatically
2. The charging time: a full charge takes about 70 minutes.
While charging, the charge progress bar (R) is ashing. After
full charge, the charge progress indicator (R) and the on/o
indicator (Q) ash.
3. The rechargeable lithium-ion battery does not need to be
removed from the charger after charging. It can stay in the
charger. It is not possible to overload it and thus it is always
ready for operation.
4. The lithium-ion battery is now ready for use.
Voltage Battery type Nominal
capacity
Number of
cells
18V Li-Ionen Akku 5 Ah 10
