Mount extruder 0(E0)
For this extruder, we will connect the wires of the hotend to it.
Step1. Take one extruder and mount it on the top plate with 4 M4x12mm screw.
Step2. Thread the motor wire and the fan wire on the extruder into the metal sheet. Do
the same with the wires on the hotend. You need to use the extension wire here for the
hotend fan.
Step3. Mount the extrusion extension board on the extruder with 2 M3x5mm screws
and hexagon copper spacer.
Note: the black connector should be faced to the fan of the extruder.
Step4. Connect the wires as shown in the following picture.
Step5. Cover the extension board, fix the cover on the hexagon copper spacer with 2
M3x5mm screw.
