Geely CK Series 2007 User Manual

105
Section 2 Front Suspension
Components
LF Strut Assembly
Front Brake Hose
Clip
Connected to Brake
Connected to Brake
LF Brake Assembly
Stabilizer Bar Left Link Rod Assembly
Left lower Swing Arm Assembly
Lower Swing Arm LF Bracket
Lower Swing Arm
RF Bracket
Front Stabilizer Bar Assembly
Stabilizer Bar
Right Link Rod Assembly
RF Brake Assembly
Connected to Brake
Clip
Front Brake Hose
RF Strut Assembly
Connected
to Brake
Body
Body
Right Lower Swing Arm Assembly
Lower Trailing Arm Rear Elastic Hinge
Fixed to Shock Absorber
ABS Sensor Wire Harness
Shock Absorber
