2. DEFINITION OF MULTIPIN PLUG-IN TERMINAL
Definition of Terminal Color of Harness
1Empty
2EPS VG
3Empty
4Empty
5Empty
6Empty
7Empty
8 Combination switch (Position lamp P
9 Speed sensor groun B
10 Speed sensor power sourc RY
11 Speed sensor signal outpu YR
12 Fuel senso B
13 Alternator WR
14 Brake fluid level switc GR
15 Oil pressure switc YG
16 Rear defrost YB
1 Rear fog lamp Gr
2 Engine malfunction GY
3 Seat belt switch R
4 Power source Y
5 Engine coolant temperature senso YW
6 Park switch G
7 Power source groun B
8 Power source groun B
9ABS R
10 SRS (Main) RY
11 Engine revolution signal BBl
12 Live wire (Fire wire) WG
13 High beam lamp + RB
14 Low beam - RW
15 SRS (Sub) RG
16 Empty
Terminal No.
A
B
