Geely CK Series 2007 User Manual

215
Section 4 Front Fog Lamp Replacement
I. REMOVAL
1. Remove the front bumper.(See bumper replacement)
2. Remove the electrical connector.
3. Remove the mounting bolts (A, B as shown in the illustration).
4. Remove the front fog lamp assembly.
II. INSTALLATION
1. Install the front fog lamp assembly.
2. Install the mounting bolts.
3. Install the electrical connector.
4. Install the front bumper.
5. Adjust the condition of the vehicle.
6. Adjust the front fog lamp beam.
III. FRONT FOG LAMP BULB REPLACEMENT
1. Press and Turn counter-clockwise, then remove the dust cover
2. Pull out the bulb
3. Replace the bulb
A
B
Electrical
Connection
