87
(3) Dust cover retainer shall be assembled well, otherwise the dust seal effect will be af-
fected
(4) Dust cover fixing nut torque: 20~25N.m
(5) Make sure the shift number words on the top of shift lever ball face towards the driving
direction of the vehicle, properly tighten the set screw of the shift lever
(6) Check whether the shift control is flexible and reliable; the shift lever shall be vertical
when in neutral shift.
Section 3 Cable Type Transmission Control Module
Components
Shift Lever Assembly
E Shaped
clip plate
Cotter Pin
Big Washer
Big Washer
Cotter Pin
E Shaped clip plate
Transmission
Assembly
Cowl Baffle
Shift Control Device
Cushion
Bottom Panel
Assembly of Body
To Next Page
