Section 3 Removal & Installation
I. SRS ELECTRONICAL CONTROL UNIT (ECU)
1. Operations prior to Removal
(1) Turn the ignition switch OFF.
(2) Remove negative (-) terminal cable of the battery. Put it in a proper position or wrap it up with insulating
tape.
2. Removal procedures:
(1) Remove the central passage side cover plate (or remove auxiliary console).
(2) Remove the connectors to SRS ECU.
(3) Remove ECU.
3. Installation procedures:
(1) Install ECU.
(2) Install the connectors to SRS ECU.
(3) Install the central passage side cover plate (or install auxiliary console).
(4) Connect negative (-) terminal cable of the battery.
4. Key points for Installation:
(1) Install ECU.
(2) Check after installation.
1Turn the ignition switch ON.
2The warning light goes on within 6s, and then goes out.
(3) If the light doesn't go out, check the trouble and eliminate it.
NOTICE
1. Work must be started 60s after the negative (-) terminal cable is detached from battery. The detached
negative (-) terminal cable shall be protected with insulating tape for insulation.
2. Never attempt to dismantle or repair an ECU. If there is any trouble, replace the ECU with a new one.
3. Prevent the ECU from shock or vibration. If pitting, crack or distortion is found, replace the ECU with
a new one.
4. Every time an airbag is deployed, the ECU shall be replaced with a new one.
5. When disassembling or maintaining the parts around ECU, attention must be given to avoid contacting
the ECU.
NOTICE
If the ECU cannot be installed correctly, the airbag will not act normally.
