171
Chapter 3 Combination Meter System
Section 1 Circuit Diagram of Combination Meter and Location of
Multi-pin Plug-in Terminal
I. CIRCUIT DIAGRAM OF CONBINATION METER
Speed Signal
Ground The Sensor
Revolution Signal
Water Temperature Signa
Fuel Level Gauge
Tachometer
Speedometer
Water
Temperature Gauge
Feul Level Gauge
Odometer
High Beam Lamp
Rear Defrost Lamp
Rear Defog Lamp
Backlight
Water Temperature Warning
Power Steering
Fuel Warning
Charge
Brake Fluid
Oil Pressure
Engine Malfunction
Driver's seat belt
Park Brake
SRS(main)
SRS(sub)
