Section 4 Camshaft Replacement
Figure 49
Vane-Type Pump V-Belt
V/ Power Steering
Fan & Generator V-Belt
High Pressure Cable
Ventilation Pipe
V-Belt No.1
Cylinder Head
Cylinder
Head Gasket
Crankshaft Bearing Cap
Crankshaft Timing Belt Washer
Crankshaft Counter Gear
Wave Gasket
Snap Ring
Camshaft
Camshaft No. 2
Oil Seal
Camshaft Timing Pulley
Fan Pulley
Generator Assembly
Crankshaft Or Pulley
Cover Sub-Assembly
Timing Belt
Cover No. 2
Air Filter Assembly W/ Hose
Right Engine Mounting
Seal
