II. SPEEDOMETER INSPECTION
1. INSPECT THE INDICATING ERROR ALLOWED BY SPEEDOMETER USING A SPEEDOM-
ETER TESTER, AND INSPECT THE OPERATION OF THE ODOMETER.
NOTICE:
Tire over or under inflation will cause the reading error.
2. INSPECT INPUT SIGNAL
(a) Connect the positive (+) pole of the voltmeter to terminal A-11, and the negative (-) to the terminal A-9.
(b) When the vehicle runs at 10 Km/h, inspect the voltage between terminal A-11 and A-9 of the combination
meter.
Standard: 7 wave forms of the high-low electrical level change per second.
NOTICE:
Hold the ignition switch ON when inspected, connect the connector.
3. INSPECT TACHOMETER
Inspect its operation
(1) Start the engine, using a handy tachometer to compare.
(2) The value displayed on the handy tachometer and the value indicated on the tachometer are as follows.
Meter indication Value displayed on the tester
20 17—23
40 35—40
60 55—60
80 75—80
100 95—100
120 114—120
140 133—140
160 152—160
180 171—180
Analog Meter (Km/h)
