191
Standard
NOTICE:
Connector should be disconnected when measured.
6. INSPECT WATER TEMPERATURE WARNINGLIGHT
(a) Disconnect the water temperature sensor connector.
(b) Turn the ignition ON, the water temperature warning light should go out.
(c) Ground the terminal B5 of the meter connector, the water temperature warning light should light up.
7. INSPECT OIL PRESSURE WARNING LIGHT
(1) Disconnect the oil pressure sensor connector.
(2) Turn the ignition ON, the oil pressure warning light should go out.
(3) Short connector terminal to the ground with a wire, the oil pressure warning light should light up.
8. INSPECT OIL PRESSURE SENSOR
(1) Disconnect the connector from the oil pressure sensor .
(2) Inspect continuity between its terminal and ground.
Engine is stopped: Continuity
Engine runs: No continuity
9. INSPECT PARK BRAKE WARING LIGHT
(1) Disconnect the connector from the park brake switch.
(2) Turn the ignition ON, the park brake warning light should go out.
(3) Short connector terminal to the ground with a wire, the park brake warning light should light up.
Standard indication Resistance (Ω)
ï¼£
159.5—169.5
1/2
Ｈ
53—59
Warning point 26.7—30.7
H 20—24
