5. DOOE COURTESY LAMP SWITCH ( ON DOOR LOCK ACTUATOR)
Inspect door courtesy lamp switch for continuity.
Inspect continuity between the terminal and the ground when the switch operates.
If it is not as specified, replace the switch.
6. REAR TRUNK LAMP SWITCH ASSEMBLY
Inspect rear trunk lamp switch for continuity.
Inspect continuity between the terminal and the ground when the switch operates.
If it is not as specified, replace the switch.
7. ROOM LAMP ASSEMBLY
Inspect each terminal on room lamp assembly for continuity.
If it is not as specified, replace the dome lamp or the switch.
Switch position Tested terminal Condition
ON 1 – Ground the body Continuity
OFF 1 – Ground the body No continuity
Tested terminal Condition
ON 1-2 Continuity
OFF 1-2 2-3 No continuity
DOOR (The door is ajar) 2-3 Continuity
DOOR (The door is closed) 2-3 No continuity
ON (Switch is pressed) 1-2 Continuity
OFF 1-2 No continuity
Switch position
Interior dome lamp
LR and RR reading lamps
Switch position Tested terminal Condition
ON (The door is well closed) 1 – Ground the body Continuity
OFF (The door is ajar) 1 – Ground the body No continuity
1
2
3
