Geely CK Series 2007 User Manual

257
5 Remove left trim plate.
6 Loosen all the SRS unit connectors.
7 Check the wire harness between the connector terminals of SRS unit and that of clock spring for the
following:
 Ground.
 Short circuit with power supply.
 Open circuit.
8 Is the above-mentioned wire harness normal?
9 Normal: completion of trouble diagnosis, and install all the parts.
 Abnormal: replace the wire harness.
6. Passenger side trouble
DIAGNOSTIC PROCEDURES
(1) Is there any passenger airbag assembly installed on the vehicle?
Yes: continue with next step.
No: continue with step (5).
(2) Check the cautions of passenger airbag assembly connector
 If it is not handled properly, the airbag assembly may be triggered and deployed, leading to serious injury
to a person. Therefore, prior to handling, read the service cautions carefully.
See service cautions for SRS.
DTC
B1 352
B1 353
B1 354
B1 355
CAUTION
●
If it is not handled properly, the airbag assembly and retractable seat belt may be
triggered and deployed/tensioned, leading to serious injury to a person. Therefore, prior
to handling, read the service cautions carefully.
See service cautions for SRS.
If there is passenger airba
g
●
The resistance between pins 13 and 14 of SRS unit connector is out of range
●
The wire harness between pins 13 and 14 of the SRS unit is short circuite
d
●
Pins 13 and 14 of the SRS unit connector are open circuited, e.g. there is no
p
assenger airbag
●
Passenger airbag assembly trouble
●
Trouble of the connector between passenger airbag assembly and SRS ECU
●
Trouble of the connector between the SRS unit and ground point
●
The circuit between passenger airbag assembly and SRS ECU is open or short
●
The circuit between SRS unit and ground point is open or shor
t
●
SRS unit trouble
Passenger airbag assembly trouble (high or low resistance, short circuit, ground, etc.)
Checking
conditions
Possible Cause
