II. Non-DTC Problem Inspection Table
1 With ignition switch ON (Engine Off),
the ABS warning light does not go on
Likely Causes
[Description]
ABS Warning Light does not go
on, the likely cause may be the open in the
warning light power supply circuit, burned bulb
or damaged warning light drive module.
 Burned fuse
 ABS Warning Light Bulb burned
 Power supply circuit open
 ABS Warning Light Drive Module damaged
Check the ABS warning light
fuse in the fuse block
Remove the ECU connector,
does the warning light goes on
with the ignition switch ON?
Check whether the ABS
warning light is burned
Check whether the warn-
ing light power supply cir-
cuit and ground circuit in the
wire harness is open
Check the connector of the
warning light power supply
circuit and ground circuit in
the wire harness
Does the fault reoccur?
Abn.
Replace
Repair the wire harness
No
Yes
Abn.
Abn.
Ok
Yes
No
Ok
Ok
Replace
Repair the wire
harness
Repair the connector
Check whether the wire in the
ABS wire harness connecting
the ABS warning light drive
module and the ECU is short
to ground
Yes
Replace the warning light
drive module
Yes
No
Refer to "Occa-
sional Problem
Service Key Points"
