Geely CK Series 2007 User Manual

354
Rear door
Rear door Component
1.Rear Door 2.Rear Door Hinges 3.Rear Door Lock And Door Lock Actuator
4.Rear Door Inner Trim Board 5.Power Window Motor 6.Power Window Actuator
7.Door Inside Handle 8.Door Outside Handle 9.Rear Window Glass 10.Quarter Window
11.Window Glass Regulator Run 12.Glass Run 13.Quarter Window Weatherstrip
14. Rear Door Weatherstrip A 15.Rear Door Lower Weatherstrip 16.Rear Door Weatherstrip B
17.Rear Door Lock Striker
1.Rear Door Removal/Installation
(1) Disconnect the negative (--) terminal cable from the battery.
(2) Remove the connector.
(3) Remove rear door hinges.
(4) Remove the rear door
(5) The installation is in the reverse order of the removal.
(6) Adjust the rear door. (See Rear door Adjustment)
1
2
3
4
5
6
7
8
9
10
12
13
15
11
14
17
16
