Gefen TOOLBOX - Timing Summary

36
TIMING SUMMARY
The following table lists the available graphic and video timings used by the HD
Pattern Signal Generator.
Timing Number Timing
T01 640 x 480 @ 60 Hz
T02 640 x 480 @ 72 Hz
T03 640 x 480 @ 75 Hz
T04 640 x 480 @ 85 Hz
T05 800 x 600 @ 56 Hz
T06 800 x 600 @ 60 Hz
T07 800 x 600 @ 72 Hz
T08 800 x 600 @ 75 Hz
T09 800 x 600 @ 85 Hz
T10 1024 x 768 @ 60 Hz
T11 1024 x 768 @ 70 Hz
T12 1024 x 768 @ 75 Hz
T13 1024 x 768 @ 85 Hz
T14 1280 x 960 @ 60 Hz
T15 1280 x 960 @ 85 Hz
T16 1280 x 1024 @ 60 Hz
T17 1280 x 1024 @ 75 Hz
T18 1280 x 1024 @ 85 Hz
T19 1600 x 1200 @ 60 Hz
T20 1920 x 1200 @ 60 Hz
T21 720 x 480i @ 59 Hz
T22 720 x 480i @ 60 Hz
T23 720 x 480p @ 59 Hz
T24 720 x 480p @ 60 Hz
T25 1280 x 720p @ 59 Hz
T26 1280 x 720p @ 60 Hz
T27 1920 x 1080i @ 59 Hz
T28 1920 x 1080i @ 60 Hz
T29 1920 x 1080p @ 59 Hz
T30 1920 x 1080p @ 60 Hz
