48
HD PATTERN SIGNAL GENERATOR SOFTWARE
Unique Patterns
Pattern 13 (ColorSetting) and Pattern 41 (Motion) can be selected from the top
panel buttons on the HD Pattern Signal Generator. However, they provide addi-
tion parameters which can only be modifi ed using the HD-SIGGEN software.
Motion
1. Select the Motion pattern (P41).
2. Press the Download button to retrieve current color settings of the
Motion pattern.
By default, the Motion pattern uses a block shape for the pattern.
Click the Download
button to retrieve the
current Motion
pattern settings
