gefran ADV200

ADV200 • Functions description and parameters list 173
 5510Digitalinput9Xmon BIT 16 0 0 1 ER
 5512Digitalinput10Xmon BIT 16 0 0 1 ER
 5514Digitalinput11Xmon BIT 16 0 0 1 ER
 5516Digitalinput12Xmon BIT 16 0 0 1 ER
 5518Digitalinput13Xmon BIT 16 0 0 1 ER
 5520Digitalinput14Xmon BIT 16 0 0 1 ER
 5522Digitalinput15Xmon BIT 16 0 0 1 ER
 5524Digitalinput16Xmon BIT 16 0 0 1 ER
These signals represent the state of the corresponding digital input on the expansion card..
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 1530Analoginp1 BIT 16 0 0 1 ER
This signal is active when the value of the analog input is below the threshold set in parameter 1520Analoginp1thr.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 1580Analoginp2 BIT 16 0 0 1 ER
This signal is active when the value of the analog input is below the threshold set in parameter 1570Analoginp2thr.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 2388Torquerefnofilter perc FLOAT 16 0.0 0.0 0.0 ER
The torque control reference current without lter is displayed (in Flux vector OL and eld-oriented vector mode).
Menu PAR Descrizione UM Tipo FB BIT Def Min Max Acc Mod
 2396Torquenofilter perc FLOAT 16 0.0 0.0 0.0 ER
Monitoring of the actual torque reference without lters.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 3006Speedratiooutmon rpm INT16 16 0 0 0 ER
This parameter displays the value of the speed ratio used by the “Speed draw” function (speed ratio).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 2392Torqueref1mon perc FLOAT 16/32 0.0 -300.0 300.0 ERW
The total value of torque reference 1 is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 3180Brakecontrolmon rpm INT16 16 0 0 1 ER
This parameter displays the status of the brake command.
0 Brake closed
1 Brake open
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 3192Brakeopenthrmon perc FLOAT 0 0.0 0 ERS
Brake opening threshold value. Only if Hoistmode2 has been selected.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
 3214Motoroverloadtrip BIT 16 0 0 1 ER
This signal is active when the drive is in the motor overload alarm condition.
