ADV200 • Functions description and parameters list 19
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4.3 554 Accessmode ENUM Easy 0 1 RW FVS
With this parameter you can restrict access to advanced conguration.
0 Easy
1 Expert
The Easy mode gives access to a list of parameters that can be used for rapid drive commissioning. This type
of conguration is suitable for the majority of applications.
Setting the parameter to Expert gives access to all the parameters in the rmware. This mode allows an ex-
tremely high level of customization to be achieved in order to exploit the potential of the ADV200 to the full.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4.4 558 Applicationselect ENUM None 0 2 ERWZ FVS
Selection of which IEC 61131-3-compliant application.
0 None
1 Application 1
2 Application 2
The drive is supplied already incorporating a number of applications developed in the IEC 61331-3 environ-
ment. To use these, set the desired application, run save parameter, switch the drive off and then on again.
NOTE! The LoadDefaultcommand (par. 580) does not modify this parameter
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4.5 560 Mainsvoltage ENUM 400 V SIZE SIZE ERWZS FVS
Setting of the available mains voltage value in Volts. Detection of the undervoltage alarm refers to this value.
0 None
1 230 V
2 380 V
3 400 V
4 415 V
5 440 V
6 460 V
7 480 V
8 500 V
9 575 V
10 690 V
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4.6 586 DCsupply ENUM None 0 3 ERWZS FVS
Selection of the voltage applied to the DC link if the drive is powered by an AC/DC power supply unit, whether
standard or regenerative (e.g. AFE200). If a value of other than “None” is selected, all parameters that depend
on Mainsvoltage (PAR 560) are calculated on the basis of the voltage shown in the table below, while the
value of PAR 560 Mainsvoltage is set automatically.
If “None” is selected, these parameters are calculated according to the value of parameter 560 Mainsvoltage.
DCpowersupply
Drivefamily380V..480V
Mainsvoltage
Drivefamily690V
Mainsvoltage
0 None Use P560 Use P560
1 540 V (380-480V) 400 V N/A
2 650 V (380-480V) 460 V N/A
3 750 V (380-480V) 460 V N/A
