gefran ADV200

20 ADV200 • Functions description and parameters list
DCpowersupply
Drivefamily380V..480V
Mainsvoltage
Drivefamily690V
Mainsvoltage
10 675 V (690V) N/A 500 V ( if compatible with the size, otherwise N/A )
11 810 V (690V) N/A 575 V ( if compatible with the size, otherwise N/A )
12 935 V (690V) N/A 690 V
13 1120 V (690V) N/A 690 V
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4.7 450 Undervoltage V FLOAT CALCF CALCF CALCF ERWZS FVS
Setting of the drive minimum operating voltage. The maximum and minimum default values are calculated auto-
matically by the drive according to the value set in parameter 560 Mainsvoltage, as shown in the table below.
Table of undervoltage limits
Mainsvoltage Def Min Max
0 None (Vdc) (Vdc) (Vdc)
1 230 V 225 200 282
2 380 V 372 330 466
3 400 V 392 330 490
4 415 V 407 360 509
5 440 V 431 382 539
6 460 V 451 400 564
7 480 V 470 417 588
8 500 V 490 434 613
9 575 V 563 500 705
10 690 V 676 600 846
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4.8 562 Switchingfrequency ENUM SIZE SIZE SIZE ERWS FVS
Setting of the switching frequency value in kHz. The maximum value that can be set depends on the size of the drive.
0 1 kHz
1 2 kHz
2 4 kHz
3 6 kHz
4 8 kHz
5 10 kHz
6 12 kHz
7 16 kHz
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4.9 564 Ambienttemperature ENUM 40 degC 0 1 ERWZ FVS
Setting of the ambient temperature value. This parameter is used to set the output current derating factor (1%
for every °C above 40°C).
0 40 degC The inverter is capable of delivering direct current continuously with ambient temperatures of up
to 40°C.
1 50 degC The inverter is capable of delivering direct current continuously with ambient temperatures of up
to 50°C.
If the value is set to 1 the drive output current will be 10% less than the rated current at 40°C.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4.10 566 Driveoverloadmode ENUM Heavy duty 1 2 ERWZ FVS
Setting of the overload that can be supplied by the drive, depending on the application.
1 Heavy duty
2 Light duty
Set Heavyduty when a large overload is requested:
• (asynchronous motor control) the drive can supply 180% of the rated current for 0,5 seconds and 150%
