gefran ADV200

ADV200 • Parameters List 229
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
10 Input&ref=upp
11 Freeze input
8.8 884 Mpot up src LINK 16 6000 0 16384 RW FVS
L_DIGSEL2
8.9 886 Mpot down src LINK 16 6000 0 16384 RW FVS
L_DIGSEL2
8.10 888 Mpot invert src LINK 16 6000 0 16384 ERW FVS
L_DIGSEL2
8.11 890 Mpot preset src LINK 16 6000 0 16384 ERW FVS
L_DIGSEL2
8.12 892 Mpot mode ENUM Fine&Last val 0 3 ERW FVS
0 Ramp&Last val
1 Ramp&Follow
2 Fine&Last val
3 Fine&Follow
8.13 894 Mpot output mon rpm INT16 16/32 0 0 0 ER FVS
9-JOGFUNCTION
9.1 910 Jog setpoint rpm INT16 0 CALCI CALCI RW FVS
9.2 912 Jog acceleration s FLOAT 5.0 0.01 1000.0 RW FVS
9.3 914 Jog deceleration s FLOAT 5.0 0.01 1000.0 RW FVS
9.4 916 Jog cmd + src LINK 16 6000 0 16384 RW FVS
L_DIGSEL2
9.5 918 Jog cmd - src LINK 16 6000 0 16384 RW FVS
L_DIGSEL2
9.6 920 Jog output mon rpm INT16 16/32 0 0 0 ER FVS
10-MONITORFUNCTION
10.1 930 Reference 0 thr rpm INT16 30 0 CALCI RW FVS
10.2 932 Reference 0 delay ms UINT16 400 0 10000 RW FVS
10.3 940 Speed 0 thr rpm INT16 30 0 CALCI RW FVS
10.4 942 Speed 0 delay ms UINT16 400 0 10000 RW FVS
10.5 950 Speed threshold 1 rpm INT32 0 CALCI CALCI RW FVS
10.6 952 Speed threshold 2 rpm INT32 0 CALCI CALCI RW FVS
10.7 954 Speed threshold dly ms UINT16 0 0 50000 RW FVS
10.8 960 Set speed ref src LINK 16/32 628 0 16384 ERW FVS
L_CMP
10.9 962 Set speed error rpm INT16 100 0 CALCI RW FVS
10.10 964 Set speed delay ms UINT16 0 0 50000 RW FVS
10.11 968 Dig set speed ref rpm INT16 16/32 0 CALCI CALCI ERW FVS
10.12 970 Speed threshold 3 rpm INT32 0 0 CALCI RW FVS
10.13 972 Speed thr hysteresis rpm INT16 0 0 CALCI RW FVS
10.14 980 Current threshold perc INT16 100 0 200 RW FVS
10.15 982 Current thr hyster perc INT16 0 0 100 RW FVS
11-COMMANDS
11.1 1000 Commands remote sel ENUM Terminal 0 1 RWZ FVS
0 Terminal
1 Digital
11.2 1002 Commands local sel ENUM Keypad 0 1 ERWZ FVS
0 Terminal
2 Keypad
11.3 1004 Enable/disable mode ENUM Stop/FS&Spd=0 0 3 ERW FVS
