gefran ADV200

230 ADV200 • Parameters List
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
0 Off
1 Stop/FS&Spd=0
2 Stop&Spd=0
3 FS&Spd=0
11.4 1006 Speed 0 disable dly ms UINT16 1000 0 10000 ERW FVS
11.5 1008 Stop key mode ENUM Inactive 0 1 ERW FVS
0 Inactive
1 EmgStop&Alarm
11.6 1010 Commands safe start BIT 1 0 1 ERW FVS
11.7 1012 Dig local/remote ENUM 16 Remote 0 1 ERW FVS
0 Local
1 Remote
11.8 1014 Local/remote src LINK 16 1012 0 16384 ERW FVS
L_DIGSEL3
11.9 1016 Terminal Start src LINK 16 1048 0 16384 ERW FVS
L_DIGSEL2
11.10 1018 Digital Enable src LINK 16 6000 0 16384 ERW FVS
L_DIGSEL2
11.11 1020 Digital Start src LINK 16 6000 0 16384 ERW FVS
L_DIGSEL2
11.12 1022 FastStop src LINK 16 6000 0 16384 ERW FVS
L_DIGSEL2
11.13 1024 Enable cmd mon BIT 16 0 0 1 R FVS
11.14 1026 Start cmd mon BIT 16 0 0 1 R FVS
11.15 1028 FastStop cmd mon BIT 16 0 0 1 R FVS
11.16 1040 FR mode ENUM Two wire 0 2 ERWZ FVS
0 Normal
1 Two wire
2 Three wire
11.17 1042 FR forward src LINK 16 1112 0 16384 ERW FVS
L_DIGSEL2
11.18 1044 FR reverse src LINK 16 1114 0 16384 ERW FVS
L_DIGSEL2
11.19 1046 FR *stop src LINK 16 6000 0 16384 ERW FVS
L_DIGSEL2
11.20 1048 FR start mon BIT 16 0 0 1 ER FVS
11.21 1050 FR reverse mon BIT 16 0 0 1 ER FVS
11.22 1052 FR cmd mon UINT16 0 0 0 ER FVS
11.23 1032 Drv interlock src LINK 16BIT 6002 0 16384 ERW FVS
L_DIGSEL2
11.24 1034 Drv interlock mon BIT 16BIT 0 0 1 ER FVS
11.25 1036 FastStop mode ENUM Not Latched 0 1 ERW FVS
0 Not Latched
1 Latched
12-DIGITALINPUTS
12.1 1132 Dig inp 1 inversion BIT 0 0 1 RW FVS
12.2 1134 Dig inp 2 inversion BIT 0 0 1 RW FVS
12.3 1136 Dig inp 3 inversion BIT 0 0 1 RW FVS
12.4 1138 Dig inp 4 inversion BIT 0 0 1 RW FVS
12.5 1140 Dig inp 5 inversion BIT 0 0 1 RW FVS
12.6 1150 Digital input E dest ILINK 0 0 0 ER FVS
12.7 1152 Digital input 1 dest ILINK 0 0 0 ER FVS
