264 ADV200 • Parameters List
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
27.3.6 2166 E1 Abs revolutions UINT32 32BIT 0 0 0 ER FVS
27.3.7 5152 E2 Virtual pulses UINT32 CALCI 0 0 ERW FVS
27.3.8 5154 E2 Virtual position cnt UINT32 32BIT 0 0 0 ER FVS
27.3.9 5156 E2 Revolutions INT32 32BIT 0 0 0 ER FVS
27.3.10 5168 E2 Abs pulses UINT32 CALCI 0 0 ER FVS
27.3.11 5252 E3 Virtual pulses UINT32 CALCI 0 0 ERW FVS
27.3.12 5254 E3 Virtual position cnt UINT32 32BIT 0 0 0 ER FVS
27.3.13 5256 E3 Revolutions INT32 32BIT 0 0 0 ER FVS
27.3.14 2136 Resolver MIS maxThr V FLOAT 2.280 0.000 4.820 ERWZ FVS
27.3.15 2138 Resolver MIS minThr V FLOAT 3.990 0.000 4.820 ERWZ FVS
27.3.16 2140 Resolver LOT thr deg FLOAT 4 0 9 ERWZ FVS
27.3.17 2142 Resolver LOT hys deg FLOAT 0.5 0 9 ERWZ FVS
27.3.18 2144 Resolver get reg UINT16 0 0 0 ERWZ FVS
27.3.19 2146 Resolver reg mon UINT16 0 0 0 ERZ FVS
27.4-SERVICE/FIELDBUSSERV
27.4.1 4016 Fieldbus float order BIT 0 0 1 ERW FVS
27.4.2 4018 Profibus byte order BIT 0 0 1 ERW FVS
27.4.3 5604 InputSize UINT16 0 0 65535 ER FVS
27.4.4 5606 OutputSize UINT16 0 0 65535 ER FVS
27.4.5 5614 PN diagnostic UINT32 0 0 4294967295 ERW FVS
27.5-SERVICE/EXTIOSERV
27.5.1 5488 External IO period UINT16 8 8 64 ERW FVS
27.5.2 5490 External IO address INT16 1 1 255 ERW FVS
27.5.3 5492 External IO baudrate ENUM 500k 0 12 ERW FVS
0 Auto
1 125k
2 250k
3 500k
4 1M
5 9600
6 19200
7 93750
8 187,5k
9 1,5M
10 3M
11 6M
12 12M
27.6-SERVICE/SERIALNUMBERS
27.6.1 520 Product S/N UINT32 0 0 0 R
27.6.2 522 Regulation S/N UINT32 0 0 0 R
27.6.3 524 Power S/N UINT32 0 0 0 R
27.6.4 536 Slot1 card S/N UINT32 0 0 0 R
27.6.5 538 Slot2 card S/N UINT32 0 0 0 R
27.6.6 540 Slot3 card S/N UINT32 0 0 0 R
27.7-SERVICE/SENSORLESS
27.7.1 3356 Magn curr speed zero % UINT32 150 50 200 ERW S
27.8-SERVICE/MULTIWINDING
