34 ADV200 • Functions description and parameters list
7.7 812 Multireference6 FF INT16 0 CALCI CALCI RW FVS
7.8 814 Multireference7 FF INT16 0 CALCI CALCI RW FVS
7.9 816 Multireference8 FF INT16 0 CALCI CALCI ERW FVS
7.10 818 Multireference9 FF INT16 0 CALCI CALCI ERW FVS
7.11 820 Multireference10 FF INT16 0 CALCI CALCI ERW FVS
7.12 822 Multireference11 FF INT16 0 CALCI CALCI ERW FVS
7.13 824 Multireference12 FF INT16 0 CALCI CALCI ERW FVS
7.14 826 Multireference13 FF INT16 0 CALCI CALCI ERW FVS
7.15 828 Multireference14 FF INT16 0 CALCI CALCI ERW FVS
7.16 830 Multireference15 FF INT16 0 CALCI CALCI ERW FVS
It is possible to select up to 16 operating frequencies, which can be set in these parameters.
The frequencies are selected using the binary code of the digital inputs programmed using the Multirefsel0
src, Multirefsel1src, Multirefsel2src and Multirefsel3src parameters.
References can be set via the keypad, serial line, digital inputs and BUS.
A sign can be given to the references, so that when they are dened so too is the desired direction of rotation.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
7.17 832 Multiref0src LINK 16/32 800 0 16384 RW FVS
7.18 834 Multiref1src LINK 16/32 802 0 16384 RW FVS
Selection of the origin (source) of the drive speed reference signals. The speed reference values can be se-
lected from those listed in the “L_MLTREF” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
7.19 840 Multirefsel0src LINK 16 6000 0 16384 RW FVS
7.20 842 Multirefsel1src LINK 16 6000 0 16384 RW FVS
7.21 844 Multirefsel2src LINK 16 6000 0 16384 RW FVS
7.22 846 Multirefsel3src LINK 16 6000 0 16384 ERW FVS
Selection of the origin (source) of the signals used to select one of the preset speeds. These parameters can
only be used together in combinations. The terminals that can be used for this function can be selected from
among those listed in the “L_DIGSEL2” selection list.
The following table describes the selection of the Multispeed function:
Activespeedref Multirefsel0src Multirefsel1src Multirefsel2src Multirefsel3src
Multi reference 0 0 0 0 0
Multi reference 1 1 0 0 0
Multi reference 2 0 1 0 0
Multi reference 3 1 1 0 0
Multi reference 4 0 0 1 0
Multi reference 5 1 0 1 0
Multi reference 6 0 1 1 0
Multi reference 7 1 1 1 0
Multi reference 8 0 0 0 1
Multi reference 9 1 0 0 1
Multi reference 10 0 1 0 1
Multi reference 11 1 1 0 1
Multi reference 12 0 0 1 1
Multi reference 13 1 0 1 1
