ADV200 • Functions description and parameters list 49
When the parameter is set to Keypad the origin of the Enablecmdmon and Startcmdmon commands is
the Start key. When Keypad is set to generate the Enablecmdmon command, as well as the Start key the
enable hardware command must also be sent to the Enable terminal (7).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.3 1004Enable/disablemode ENUM Stop/FS&Spd=0 0 3 ERW FVS
This parameter is used to dene the generation of Enablecmdmon, i.e. to congure the type of control used
for enabling and disabling the drive.
0 Off
1 Stop/FS&Spd = 0
2 Stop&Spd = 0
3 FS&Spd = 0
If set to 0Off:
In Terminal mode the drive is enabled and disabled via the Enable terminal.
In Digital mode the drive is enabled and disabled when the signal on the Enable terminal and the DigitalEn-
able command are present simultaneously.
In Keypad mode the drive is enabled if the hardware is enabled on the Enable terminal and the Start key is
pressed.
In Keypad mode it is disabled if the hardware is not enabled on the Enable terminal or if the Stop key is
pressed twice.
If 1Stop/FS&Spd=0 is set:
In Terminal mode the drive is enabled when the hardware is enabled on the Enable terminal, on the terminal
programmed as TerminalStart and the FastStop terminal must not be enabled.
In Terminal mode the drive is instantly disabled if there is no signal on the Enable terminal, or when speed=0
is reached if the Startcommand is disabled or the terminal programmed as FastStop is enabled.
In Digital mode the drive is enabled when the hardware is enabled on the Enable terminal, the DigitalEnable,
In Digital mode the drive is instantly disabled if there is no signal on the Enable terminal, or when speed=0 is
reached if the DigitalStart command is disabled or the terminal programmed as FastStop is enabled.
In Keypad mode the drive is enabled if the hardware is enabled on the Enable terminal and the Start key is
pressed, with the command disabled on the FastStop terminal.
In Keypad mode the drive is disabled instantly if the signal is not present on the Enable terminal or the Stop
key is pressed twice.
If 2Stop&Spd=0is set:
In Terminal mode the drive is enabled if the hardware is enabled on the Enable terminal and the signal is ena-
bled on the terminal programmed as TerminalStart.
In Terminal mode the drive is instantly disabled if there is no signal on the Enable terminal, or if, upon reaching
the speed=0, the TerminalStart command is disabled.
In Digital mode the drive is enabled when the hardware is enabled on the Enable terminal and the DigitalEn-
able and DigitalStart signals are present.
In Digital mode the drive is instantly disabled if the signal is not present on the Enable terminal, or the Digital
Enable command is not present, or upon reaching the speed=0 if the DigitalStart command is set to 0.
In Keypad mode the drive is enabled when the hardware is enabled on the Enable terminal and the Start key
is pressed.
In Keypad mode the drive is instantly disabled if the signal is not present on the Enable terminal or the Stop
key is pressed twice, or when the speed=0 is reached if the Stop key is pressed.
If 3FS&Spd=0 is set:
In Terminal mode the drive is enabled when the hardware is enabled on the Enable terminal and the FastStop
