gefran VDI100 Start-Up And Installation Manual

3.7. Inverter Specications
Sizes VDI100
1007 1015 1022 2037 2055 3075 3110 3150
4150-F
4185 4220 5300 5370 5450
Output Rating
(2)
HD
(3)
Rated Output Capacity
kVA
2.6 3.2 4.2 7 11.3 13.7 18.3 23.6 29.7 34.3 45.7 57.2 69.3
Rated Output Current
A
3.4 4.2 5.5 9.2 14.8 18 24 31 39 45 60 75 91
Maximum Applicable
Motor
(1)
HP
1 2 3 5 7.5 10 15 20 25 30 40 50 60
kW
0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45
ND
(4)
Rated Output Capacity
kVA
3.1 4.1 5.3 9.2 13.3 17.5 23.6 29.0 33.5 44.2 55.6 67.1 78.5
Rated Output Current
A
4.1 5.4 6.9 12.1 17.5 23 31 38 44 58 73 88 103
Maximum Applicable
Motor
(1)
HP
2 3 5 7.5 10 15 20 25 30 40 50 60 75
kW
1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55
Maximum Output Voltage
V
Three-Phase, 380V to 480V
Maximum Output
Frequency
Hz
0.1~599 (Based on parameter setting)
Input Power
Rated Voltage, Frequency Three-Phase, 380V to 480V, 50/60Hz
HD
Rated Input Current
A
3.7 5.3 6.0 9.6 15.5 18.7 25.0 33.7 42.4 48.9 65.2 81.5 98.9
ND
A
4.5 5.9 7.5 11.6 18.2 24.0 32.3 41.3 47.8 58.7 78.3 95.7 112
Allowable Voltage Fluctuation -15% ~ +10%
Allowable Frequency Fluctuation ±5%
Braking Transistor Built-in
Option (External
Braking Module)
(1) Based on the standard 4-pole induction motor. The selected inverter must have a higher output current rating than the motor.
(2) The default setting of VDI100 is HD (heavy duty mode). To switch VDI100 to ND (normal duty mode) set parameter (00-27) to 1. When switching to ND (normal duty mode),
the frequency will change to 2kHz.
(3) The default setting of carrier frequency in HD mode is shown into the table below, if the setting value is higher than default setting, derating may be required.
(4) The default setting of carrier frequency in ND mode is 2kHz, if the setting value is higher than default setting, de-rating may be required.
(5) If control mode is set to SLV mode and maximum frequency is larger than 80Hz, the carrier frequency range is 2~8kHz.
(6) Option (External Braking Module)
Inverter Voltage and
Power
HD mode carrier freq
range
HD mode carrier
freq default setting
0.75 ~ 22 kW 2~16 kHz 8 kHz
30 ~ 37 kW 2~12 kHz
(5)
5 kHz
45 kW 2~10 kHz
(5)
5 kHz
The following table shows maximum output frequency for each control mode.
Duty Cycle Control mode (*) Other settings Maximum output frequency
Heavy Duty
(00-27=0)
V/f
V/f + PG, SLV2
maximum frequency set to 599Hz 599Hz
SLV
0.75~11 kW 150Hz
15 kW 110Hz
18.5 ~ 22 kW 100Hz
30~45kW carrier (11-01) is set as 8K or below 8K 100Hz
30~45kW carrier (11-01) is above 8K 80Hz
SV Full range 599Hz
PMSV Full range Twice of Base frequency
PMSLV Full range Base frequency
Normal Duty
(00-27=1)
V/f
V/f + PG
maximum frequency set to 120Hz 120Hz
SLV /SV
PMSV/ PMSLV
SLV2
No normal duty mode
(*) See PAR 00-00 Control mode selection (ch. “4.4. Description of Parameters” a pagina 89 of VDI100 UM manual).
18 VDI100 • Start-up and Installation Manual
